CD-2500 Crankshaft Crack Detector
The AMC-SCHOIU Crack Detectors are the perfect choice when it comes to fincing cracks in steel and iron components.
The cracks will be shown up as white on a green background. Fluorescent ink is supplied with a spray bottle. Supplied with UV lamp and heavy duty cableswhich allow remote inspection of larger components.
Crack Detector
For inspection of cracks in steel and iron components. The component demagnetises automatically.
|
TECHNICAL SPECIFICATIONS |
CD-2500 |
|
|
Max. inspection of cracks in steel and and iron comp |
mm |
2500 |
|
Max. output |
Amp |
3000 at 7V AC |
|
Max. operating current draw |
Amp |
50 at 380/440 V |
|
Power of UV lamp |
W |
125 |
|
Length of heavy-duty cables (2 pcs) |
mm |
2500 + 3700 |
|
Height table to top of guard |
mm |
790 |
|
Dimensions |
||
|
Height of machine |
mm |
2030 |
|
Total length of machine |
mm |
2520 |
|
Total width of machine |
mm |
585 |
|
Net. weight approx. |
kg |
450 |
|
Shipping weight approx. (wooden box) |
kg |
500 |
|
Shipping volume |
m³ |
2.92 |
We are engaged in a continuous process of improving our machines. The details associated with any descriptions, specifications and illustrations shown may thus vary without further notice.
· Detects cracks in all ferrous material.
· Demagnetises automatically
· Inspection by ultra-violet light
· Easy to operate.
