RGT10 Hydro Pneumatic Riveting Machine

Carmec RGT 10 Hydro Pneumatic Riveting Machine

The hydro-pneumatic riveting machine Carmec RGT 10 allows to rivet and derivet the brake linings on every type of brake shoe. The heavy duty steel structure gives excellent qualities of strenght and rigidity at the machine, while the combined hydraulic and pneumatic acting system assures an high working force using a low quantity of compressed air which is treated by a filter-lubricator group complete of pressure regulator and an easy reading manometer.

Rivets diameter 3÷12 mm
Working pressure 3÷10 bar
Max punch force 5200 Kg
Max punch stroke 45 mm
Dimensions (L×W×H) 350×700×1650 mm
Weight 155 kg
