Standard Equipment

• CNC (Computer Numerical Control) Machine using Windows Operating System and Industrial PC with Intel Processor. Precision Programming and Control  thru a 15" (400mm) Computerized Touch Screen.

• Software options available for Programmable & Automated Cycles such as Boring, Surfacing, Lower Sleeve Offset Boring, Water Hole Repairs, Main & Cam Line Boring, General CNC Machine Work

• USB flash drive for file transfer to and from computer

• Internet connection to the machine computer must be provided for training support and service.

• Machine/Computer can operate in either inch or metric system

• 3 Axis movement by Direct Drive Precision Ball Screws

• All motors - AC Servo Motors - Infinitely Variable

• Horizontal Movement (X Axis) - Left and Right Direction – 72” (1830mm)

• Horizontal Movement (Y Axis) - In and Out Direction – 12” (305mm)

• Vertical Movement (Z Axis) - Up and Down – 18” (457mm)

• Vertical, Horizontal and Spindle Load Monitoring for Fast Overload Shut Down

• Precision Position Display in .0001" (.002mm) Resolution.

• Electronic Handwheel for manual movement - per click: Coarse Mode .01" (.25mm) Medium Mode .001" (.01mm) Fine Mode .0001" (.002mm)

• Infinitely Variable Feedrates adjustable by handwheel during automatic cycles

• High Performance Spindle Rotation AC Brushless Servo Motor and Drive System

• Hard Chromed Precision Spindle with High Speed Angular Contact Bearings

• CAT40 Spindle Taper with Pneumatic Quick Change Tool System

• Fast Rapid and Jog Speeds for Reduced Cycle Time

• Automatic Workhead Tilt System for Back Clearance during Surfacing

• One Piece Heat Treated Mehanite Cast Iron Machine Castings

• Air Pressurized Column for Less Friction and Accurate Positioning

• Turcite Coated Slideways for Low Friction and Extended  Life

• Automatic Central Lubrication System monitored by computer

• LED Work Light (mounted)

• Chip Guard with Adjustable Pivot Arm

• Operation, Programming and Spare Parts Manual - Digital
