ProductionHone Mini E1000S
Tax excluded. Shipping calculated at checkout
With programmable precision, and de-skilled operational efficiency, the ProductionHone series provides reliable and cost effective production honing. ProductionHone Mini (E1000S) is ideal for small to medium batches, honing diameters of 1.14 – 25mm. A choice of fixtures and full adjustability make this machine hugely flexible – it is an invaluable staple in engineering production environments.
For B2B customers, please register here for EU VAT exemption.
ProductionHone Mini E1000S
Sale price€0,00
CHARACTERISTICS
- Electronic control system with Siemens’ digital HMI
- Fully adjustable stroke length and speed
- Fully adjustable spindle speed
- Unique spindle system with integral stone expansion
- Multi-plane spindle nose
- Feed movement via precision ballscrew
- Stable, accurate and repeatable stone adjustment
- Universal fixture as standard
- Choice of fixtures for wide range of applications
- Alignment gauge option
- Semi-automatic, de-skilled operation
MACHINEPARTS
Capacity and Stroke
- Diameter range 1.14 – 25mm
- Maximum stroke length Fully adjustable (3-320mm)
- Stroking motor speed Fully adjustable (1 – 25m/min)
- Stroking motor power 3.0 Nm
- Stroking movement Precision reciprocating ball screw
- Short stroking Fully programmable length and frequency
- Spindle speed Fully adjustable 300 - 2500 RPM
- Spindle motor power 1,5 kW
- Braking Dynamic braking resistor
- Feed type Programmable electro-mechanical
- Feed rate 2 Programmable speeds for each cycle + timer
- Incremental feed 0.1 micron increments per second
- Feed movement Precision ball screw
- Stone pressure Programmable to 670N
- Wedge retraction Programmable
- Wedge retraction speed Programmable
- Conformity CE approved. Conforms to Machine Directive 2006/42/EC
- Motor protection category IP54
- Standard electrical supply 380 – 415V, 3 Phase, 50Hz
- Control voltage 24VDC
- Net 700kg
- Gross 800kg
- Dimensions 1780mm (W) x 1130mm (D) x 1860mm (H)
